ATEX aluminum explosion proof box is a product that has obtained ATEX explosion proof and is used for various purposes in various industries, including factory warehouses, and is additionally coated after polarization for protection. The ATEX aluminum explosion box is IP67 rated for protection against dust, especially for 30 minutes at a depth of 1 meter. The ATEX aluminum explosion box is available in 12 different sizes for a variety of applications where explosion proof is required.



Nomenclature
  • Product name : ATEX Aluminum Box
  • Product Size : Width x length
  • Product Height : Height



Product feature
atex_feature
  • ATEX explosion proof Accreditation Model
  • Ground terminal Connected
  • Use star L wrench
  • Waterproof, dust to allow special process.
  • Mounting plates are available separately.
  • Certificates : ATEXCE ROHS
View Catalog



Product specifications
  • Color : Gray
  • Tolerance : ± 1mm
  • Thickness : 3.5T ~ 4T
  • Operating Temperature : -20℃ ~ 180℃
  • Protection rating : IP67
  • Materials: Aluminum
Model Size(mm) weight (g) Pictures
SG-AL-6171-48 61 X 71 X 48 220 View Pictures
SG-AL-7093-52 70 X 93 X 52 249 View Pictures
SG-AL-1270-52 70 X 128 X 52 360 View Pictures
SG-AL-1111-52 110 X 110 X 52 398 View Pictures
SG-AL-1770-55 70 X 172 X 55 435 View Pictures
SG-AL-1214-62 125 X 145 X 62 566 View Pictures
SG-AL-8023-08 80 X 235 X 80 844 View Pictures
SG-AL-1219-08 125 X 190 X 80 944 View Pictures
SG-AL-1212-08 120 X 120 X 80 690 View Pictures
SG-AL-1222-09 125 X 223 X 90 1314 View Pictures
SG-AL-1616-09 160 X 160 X 90 1205 View Pictures
SG-AL-1626-09 161 X 263 X 90 1699 View Pictures
CAD Download
